Core Parameters

• 1.CylinderDiameterRange:Φ40~Φ300

• 2.OutputTorque:

• DoubleAction:8~8000Nm

• SingleAction:5~4200Nm

• 3.AirSupply:2.5bar~8bar

• 4.SwitchAngle:90±5°

• 5.OperatingTemperature:-50~120°C

• 6.Flanged Connection:F03-F25

Technical Features

▶ALODUR is oxidized hard aluminum shell.

▶Double piston gear shift design, simply reverse the piston to change the direction of the execution agency's rotation

▶The integrated design, dual effects and single effects have the same cylinder and end cover, which is convenient to change the role by installing spring or removing spring.

▶Set up two independent adjustment screws accurately regulating valve opening and valve control location on the outer side

▶The high-quality aluminum alloy cylinder body is squeezed,and the inner hole and external surface of the precision processing are performed for hard anode oxidation treatment (under special circumstances,the anode oxidation+special fluoron coating),the longer life life and the low friction coefficient.
