Core Parameters

• Shell material: aluminum alloy

• Main transmission: two-stage worm gear

• Motor: duty type S2-15min (switching type); S4-25% (adjustable type); H-grade insulation

• Valve position detection: dual cam, standard heater

• Potentiometer (basic type, integrated type): Absolute value encoder (intelligent type)

• Moisture-proof heater: standard configuration

• Torque range: 100-20000 Nm

• Switching time: less than 30 seconds for the entire series

• ·Anti-corrosion coating: Epoxy resin powder coating, with a salt spray test duration of over 168 hours

• Silent design: less than 65dB

• Service environment: free of strong corrosive, flammable, and explosive media;

• Protection level: Standard configuration: IP67; Optional configuration: IP68

• ·Typical applications: butterfly valves, ball valves, plug valves, and similar applications in general areas
